Answer
Dec 06, 2016 - 12:00 AM
Feed and Speed recommendation for 3/8" passes:
60" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0019"
Depth Per Pass: 3/8"
Feed and Speed recommendation for 1/4" passes:
90" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0025"
Depth Per Pass: 1/4"
Feed and Speed recommendation for 3/16" passes:
90" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0025"
Depth Per Pass: 3/16"
Feed and Speed recommendation for 1/8" passes:
100" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0031"
Depth Per Pass: 1/8"
60" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0019"
Depth Per Pass: 3/8"
Feed and Speed recommendation for 1/4" passes:
90" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0025"
Depth Per Pass: 1/4"
Feed and Speed recommendation for 3/16" passes:
90" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0025"
Depth Per Pass: 3/16"
Feed and Speed recommendation for 1/8" passes:
100" IPM @ 18,000 RPM
Chip Load Per Tooth: 0.0031"
Depth Per Pass: 1/8"
