Answer
Oct 11, 2016 - 12:00 AM
The feed and speeds for Amana Tool numbers 46252, 46254 and 46256 can be found below:
46252:
Plastics: 100" IPM @18,000 RPM / Chip Load per tooth: 0.0029" / Depth Per Pass: 1/32"
Aluminum: 15" IPM @18,000 RPM / Chip Load per tooth: 0.0005" / Depth per pass: 1/32"
Brass: 15" IPM @18,000 RPM / Chip Load per tooth: 0.0005" / Depth per pass: 1/32"
Softwood: 110" IPM @ 18,000 RPM / Chip Load per tooth: 0.0033" / Depth per pass: 1/32"
Hardwood: 90" IPM @ 18,000 RPM / Chip Load per tooth: 0.0026" / Depth per pass: 1/32"
46254:
Plastics: 120" IPM @18,000 RPM / Chip Load per tooth: 0.0035" / Depth Per Pass: 1/16"
Aluminum: 20" IPM @18,000 RPM / Chip Load per tooth: 0.0006" / Depth per pass: 1/16"
Brass: 20" IPM @18,000 RPM / Chip Load per tooth: 0.0006" / Depth per pass: 1/16"
Softwood: 150" IPM @ 18,000 RPM / Chip Load per tooth: 0.0043" / Depth per pass: 1/16"
Hardwood: 100" IPM @ 18,000 RPM / Chip Load per tooth: 0.0029" / Depth per pass: 1/16"
46256:
Plastics: 90" IPM @18,000 RPM / Chip Load per tooth: 0.0027" / Depth Per Pass: .05mm
Aluminum: 15" IPM @18,000 RPM / Chip Load per tooth: 0.0005" / Depth per pass: .05mm
Brass: 15" IPM @18,000 RPM / Chip Load per tooth: 0.0005" / Depth per pass: .05mm
Softwood: 100" IPM @ 18,000 RPM / Chip Load per tooth: 0.0029" / Depth per pass: .05mm
Hardwood: 90" IPM @ 18,000 RPM / Chip Load per tooth: 0.0025" / Depth per pass: .05mm
