Speeds/feeds for bits #45426 and #46348 in hardwood when cutting at half the bit depth Straight Plunge Cutting Router Bits 1/2 Shank - High Production

Hi I need some help with speeds and feeds. The bits i need help with are
#45426
#46348
I would like some info on speeds and feeds cutting at half the depth of the bit with these bits cutting hard wood.
I would like the options of cutting at half the depth of the bit as i don't always cut deep cuts if that makes any sense.
sorry i am very new at this so your help would be extremely helpful and really appreciated.

Thank you for your time

Heath

Status: Open Mar 15, 2018 - 12:00 AM

Do you have the same question? Follow this Question

1answer

Answer

Mar 15, 2018 - 12:00 AM

46348:

55" IPM @ 18,000 RPM

Chip Load Per Tooth: 0.0016"

Depth per pass: 1/2"

Ramp Down Per pass: 22" IPM

45426:

70" IPM @ 18,000 RPM

Chip Load Per Tooth: 0.0019"

Depth per pass: 1"

Ramp Down Per pass: 35" IPM
