Halve recommended cut depths: Bit #45426 1/2"→1/4", Bit #46348 1/4"→1/8" Straight Plunge Cutting Router Bits 1/2 Shank - High Production

Hi.
Thank you so much for coming back to me so quickly. I am sorry for not explaining my self properly.
The Info I wanted to know was
Bit #45426 I would like to cut at 1/4" instead of 1/2"
Bit #46348 I would like to cut at 1/8" instead of 1/4"
So basically I would like to cut at Half the depth of what the recommended
Depth is for the Bit I am using.

Thank you so much again for all you help and sorry for not explaining correctly,

Take Care
Heath

Status: Open Mar 15, 2018 - 12:00 AM

Do you have the same question? Follow this Question

1answer

Answer

Mar 16, 2018 - 12:00 AM

45426:

220" IPM @ 18,000 RPM

Chip Load Per Tooth: 0.0062"

Depth Per pass: 1/4"

Ramp Down: 110" IPM

46348:

170" IPM @ 18,000 RPM

Chip Load Per Tooth: 0.0047"

Depth Per pass: 1/8"

Ramp Down: 85" IPM
